Model Highlights

Engine Great Wall H5 provides two engine choices which inject endless power to your life.4G69S4N gasoline engine:The Mitsubishi engine is technically mature and powerful with features such as high reliability, low fuel consumption and low emission, and carries an electronic immobilizer system which enhances vehicle security.GW4D20 diesel engine: Developed by Great Wall Motors in association with world leading diesel engine technology provider Bosch, the GW4D20 diesel engine features high pressure common-rail fuel direct injection, is more powerful, consumes less fuel, and reduces use-cost while satisfying off-road demand.

Professional body structure The application of special steel, the concept of dual-zone safety as well as front & rear thickened anti-collision beams, boost the anti-distortion capacity of the body and protects you in 360 degrees.

Dynamic appearance Every detail of the dynamic and elegant Great Wall H5-E conveys the designer's comprehension of modeling art. The kinetic streamline modeling and the full appearance make it a fine sight anywhere.

Interior The all-round high-tech configuration and rich entertainment system give you a superb driving and riding experience; the broad and comfortable spatial layout, flexible seat combinations and ubiquitous humanized storage space unify artistry and utility perfectly.

Exterior Appearance


Interior Decoration



Technical Parameters — Great Wall H5 European
Model 4G69 2WD/4WD 4D20 2WD/4WD
Body Parameter Length x Width x Height(mm) 4649×1810×1745(1735)
Wheelbase(mm) 2700
Kerb Mass(kg) 1725-2WD/1805-4WD 1825-2WD/1925-4WD
Ground Clearance(mm) 180
Transmission Type 5MT 6MT/5AT
Tire Size 235/65 R17
Power Parameter
Engine Type 4-cylinder inline, four-stroke, water-cooled, EFI gasoline engine 4-cylinder inline, four-stroke, water-cooled, common rail, direct injection, DOHC, inter-cooled, EGR, turbocharged diesel engine
Displacement(cc) 2378 1996
Maximum Power(kW/rpm) 100/5250 110/4000
Maximum Torque(N.m/rpm) 200/2500-3000 310/1800-2800
Emission Standard Euro IV
Chassis Parameter Brake Type Four-wheel disc brake
Suspension(Front/Rear) Double wishbone type torsion bar spring independent suspension,5-link type coil spring non-independent suspension
Due to technical improvements the above mentioned parameters will vary from time to time. Please take the parameters prevailing at the ordering time provided by the seller as the final.
Configuration  2WD 4WD
City Pilot Dignity City Pilot Dignity
Transmission 6MT 6MT
Chassis&Steering system Hydraulic Power Steering
Adjustable steering column
Four-wheel disc brake
Differential lock
External Equipments 17" Aluminum-Alloy Wheels hubs
17" Aluminum-Alloy Spare Wheels
Tail Wing
Luggage Carrier
Front boneless wiper blades
Rear wiper blades
Sunroof × × × ×
Special Anticorrosion Treatment
Internal Equipments Beige Interior Decoration
Black / Blue Interior Decoration
Leather Door Trim
Leather Steering Wheel × ×
Steering Wheel with Audio & Bluetooth Control × ×
Stainless Steel Threshold
Luggage Boot Cushion
Cargo Curtain
Seats Equipments Child Seat Fixing Device
4-Way Adjustable Front Headrest
Leather Seats
6-Way Electrically Adjustable Driver Seat
Power Heated Seats
Active/Passive Safety Dual Airbags
Children Safety Belt(KISI)
Adjustable Front Seatbelts with Pretensioner
3-Point Rear Center Seatbelt
Automatic Collision Fuel Off System
Energy Absorbing Steering Column
Rear Door Children Safety Lock
BAS(Brake Assist System)
ABS(Anti-skid Brake System)+
EBD(Electronic Brake force Distribution)
ESP (Electronic Stability Program)
Electronic Anti-glare Internal Rear View Mirror × ×
Reverse Radars × ×
Electric Back Door Lock
TPMS(Tyre Pressure Monitoring System) × ×
Immobiliser Remote Control Central Door Lock
Engine Immobiliser
Multi-media equipments Single-disc CD+USB × × × ×
MP5+RDS × ×
Reverse Camera × ×
2 high tone speakers+4 low tone speakers
CAN Communication
Glass/rear mirrior Green glass
Gray glass
Power Windows with anti-pinch Function × × × ×
Power Windows with anti-pinch Function+Automatic Closing Function × ×
Electric Rear-view Mirror w/Defroster
Electric Foldable Rear View Mirror w/Defroster / Body-colored Electric Rear View Mirror w/Turn Signal Light
Heated Wire Defrost
Lamp equipments Electric Height-ajustable Headlamps
Automatic Headlamp+Automatic Wiper
Follow-Me-Home Function
Air Conditioning Automatic Air Conditioning
Alarm system Seatbelt Unfastening Warning System
( Driver and Front Passenger)
Over 120km/h Warning
